The new generation HEKO EC190mm low-noise centrifugal fan is specially designed for air cooler and ventilation systems requiring high efficiency and silent operation. With a compact 190mm impeller and an advanced EC motor, this model ensures optimal airflow performance with reduced energy consumption. It's the perfect solution for modern HVAC applications, data centers, and compact air-cooling units.
Low Noise Performance: Advanced aerodynamics and precision balancing ensure ultra-silent operation, ideal for residential and commercial air coolers.
High Efficiency EC Motor: Electronically commutated motor improves energy efficiency by up to 30% compared with traditional AC fans.
Compact & Durable Design: The 190mm impeller size and robust casing structure make it suitable for limited-space installations.
Flexible Voltage Options: Supports 230V single-phase input for global markets.
Maintenance-Free: Brushless motor technology extends product lifespan and reduces maintenance costs.
Customization Available: OEM service for voltage, mounting frame, and air volume upon request.
Fan Model | HB190-072E230M |
Brand Name | HEKO |
Impeller Material | PA66+GF25 |
Motor Type | BLDC External Rotor Motor |
Type of Protection | IP44 |
Insulation Class | Class B |
Speed Control | 0-10VDC/PWM |
Bearing | Ball Bearing |
Signal Output | FG |
Life Expectance | 50,000 Hours |
Electrical Protection | Locked Rotor Protection |
Reverse Polarity Protection | |
Over Voltage Protection | |
Soft Start |
This centrifugal fan is widely used in:
Air cooler and evaporative cooling systems
HVAC air handling units
Data center and electronic cabinet cooling
Industrial and commercial ventilation
