This is a backward curved centrifugal fan with an impeller diameter of 190mm, relatively small size, but not small air flow. This is a more popular product, voltage of 230V, rated speed up to 4000RPM. We select materials, the factory crafted carefully, through layers of screening and with strict quality control, this is a high-efficiency, high quality centrifugal fan. Our products have a variety of models to choose from, if you are not satisfied, you can tell us your requirements, we will customize the model you need, and we are always waiting for your consultation. The HEKO EC190mm centrifugal fan offers a perfect combination of compact size and quiet performance for modern ventilation and air cooling systems. Designed with an EC external rotor motor, this fan guarantees high efficiency, stable air pressure, and a long operating life for HVAC applications.
Silent EC motor with low vibration and noise
Energy-saving design with improved airflow control
Compact impeller ideal for air cooler and small ventilation units
Available in different mounting configurations
CE/RoHS certified for global standards
| Fan model | HB190-072E230M-F |
| Rated Voltage | 230VAC |
| Rated Current | 0.9A |
| Rated Power | 120W |
| Rated Speed | 4000RPM |
| Air Flow | 900M3/H |
Fan Model | HB190-072E230M-F |
Brand Name | HEKO |
Impeller Material | PA66+GF25 |
Motor Type | BLDC External Rotor Motor |
Type of Protection | IP44 |
Insulation Class | Class B |
Speed Control | 0-10VDC/PWM |
Bearing | Ball Bearing |
Signal Output | FG |
Life Expectance | 50,000 Hours |
Electrical Protection | Locked Rotor Protection |
Reverse Polarity Protection | |
Over Voltage Protection | |
Soft Start |
Residential & commercial air coolers
Air conditioning units
Ventilation ducts and cabinets
Cooling systems in control panels
