Fan model: HA200-092D024H/ HA200-092D048H
Rated Voltage: 24/ 48VDC
Rated Current: 2.2/ 1.1A
Rated Power: 53W
Rated Speed: 2750RPM
Air Flow: 1150M3/H
Fan Model | HA200-092D024H/ HA200-092D048H |
Brand Name | HEKO |
Impeller Material | Steel and Coated in Black |
Motor Type | BLDC External Rotor Motor |
Type of Protection | IP44 |
Insulation Class | Class B |
Speed Control | 0-10VDC/PWM |
Bearing | Ball Bearing |
Signal Output | FG |
Life Expectance | 50,000 Hours |
Electrical Protection | Locked Rotor Protection |
Reverse Polarity Protection | |
Over Voltage Protection | |
Soft Start |
